Hofmann Monty 1675 SmartSpeed Swing-Arm Tire Changer

Hofmann Monty 1675 SmartSpeed Swing-Arm Tire Changer

The Monty 1675 tire changing system is ideal for handling passenger cars, light trucks, and high-performance wheel/tire assemblies. Ergonomic design and safety-enhancing features provide the technician with a safe workspace when changing a variety of tires. Locking mount/demount head offset provides maximum cosmetic safety for expensive wheels and significantly reduces the risk of harming wheel/tire assemblies.

Robust, Professional Design:

  • Precision cast and machined shoes with robust cast jaws make for precise, slop free clamping
  • Heavy-duty pneumatic valves are simple to operate and offer intuitive functionality
  • Powerful electric motor generates 1200Nm of torque to the table top to mount stiff, difficult tires

smartSpeed Model:

  • Automatically minimizes damage to tires
  • Innovative, patented technology that optimizes the torque applied to the wheel and automatically sets the maximum rotation speed of the wheel
  • Variable from 7 to 18 RPM offering the highest possible speed for maximum productivity

Ergonomic, Hand Operated Bead Breaker Control: Newly designed bead breaker is easy to use and prevents the technician from having to straddle the assembly during bead breaking.

Integrated Pressure Limiter: Stops air flow once pressure has reached 55 psi (3.5 bar) preventing accidental tire over-inflation.

Mount/Demount Head: Locking of the mount/demount head offset, which provides maximum cosmetic safety for expensive wheels and significantly reduces the risk of harming wheel/tire assemblies.

Tire Lifting Tool: Integrated bead pusher assists in the mount/demount process of the upper bead. Tire lifting tool aids the technician with the demounting process.

Swing-Arm Configuration: Quick and easy setup. Stays within a compact footprint, even with larger tire sizes. Provides an ergonomic tire changing position.

Toolbox: Attached storage compartment allows easy access for tools and accessories.

Accessories Included:

  • Lube Brush
  • 5kg Lube Bucket Holder
  • 5kg Lube Bucket
  • Plastic Rim Protector
  • Bead Breaker Sleeve
  • Wave Bead Lever
  • Wave Bead Lever Protector
            Technical Data Monty 1675 with smartSpeed
            Hofmann Part Number EEWH779CU1
            Outer-Clamping Diameter
            10″ - 24″ (25 - 610 mm)
            Inner-Clamping Diameter
            12″ - 24″ (305 - 610 mm)
            Maximum Tire Diameter
            53″ (1346 mm)
            Maximum Wheel Width
            15″ (380 mm)
            Compressed Air Supply
            110 - 170 psi (7.6 - 11.7 bar)
            Adjustable Four-Claw Clamp
            Included
            Integrated Bead-Seating Jets
            Included
            Pressure Timer
            Included
            Twin Cylinder Turntable Clamping
            Included
            Rotation Speed
            CW 7-18, CCW 7 rpm
            Bead Breaker Power
            2700 lbs (12 kN)
            Bead Breaker Range
            1.7″ - 16.3″ (43 - 414 mm)
            Recommended Floor Space (WxDxH) 53″ x 46″ x 81″
            Shipping Weight 750 lbs (340 kg)
            Power Requirements 230 V, 1 Ph, 50/60 Hz, 16 Amp
