New

EEWH779CU2

Hofmann Monty 1675 Swing-Arm Tire Changer

Hofmann Monty 1675 Swing-Arm Tire Changer

The Monty 1675 tire changing system is ideal for handling passenger cars, light trucks, and high-performance wheel/tire assemblies. Ergonomic design and safety-enhancing features provide the technician with a safe workspace when changing a variety of tires. Locking mount/demount head offset provides maximum cosmetic safety for expensive wheels and significantly reduces the risk of harming wheel/tire assemblies.

Robust, Professional Design:

  • Precision cast and machined shoes with robust cast jaws make for precise, slop free clamping
  • Heavy-duty pneumatic valves are simple to operate and offer intuitive functionality
  • Powerful electric motor generates 1200Nm of torque to the table top to mount stiff, difficult tires

Ergonomic, Hand Operated Bead Breaker Control: Newly designed bead breaker is easy to use and prevents the technician from having to straddle the assembly during bead breaking.

Integrated Pressure Limiter: Stops air flow once pressure has reached 55 PSI (3.5 Bar) preventing accidental tire over-inflation.

Mount/Demount Head: Locking of the mount/demount head offset, which provides maximum cosmetic safety for expensive wheels and significantly reduces the risk of harming wheel/tire assemblies.

Tire Lifting Tool: Integrated bead pusher assists in the mount/demount process of the upper bead. Tire lifting tool aids the technician with the demounting process.

Swing-Arm Configuration: Quick and easy setup. Stays within a compact footprint, even with larger tire sizes. Provides an ergonomic tire changing position

Toolbox: Attached storage compartment allows easy access for tools and accessories.

Accessories Included:

  • Lube Brush
  • 5kg Lube Bucket Holder
  • 5kg Lube Bucket
  • Plastic Rim Protector
  • Bead Breaker Sleeve
  • Wave Bead Lever
  • Wave Bead Lever Protector
              Technical Data Monty 1675
              Hofmann Part Number EEWH779CU2
              Outer-Clamping Diameter
              10″ - 24″ (25 - 610 mm)
              Inner-Clamping Diameter
              12″ - 24″ (305 - 610 mm)
              Maximum Tire Diameter
              53″ (1346 mm)
              Maximum Wheel Width
              15″ (380 mm)
              Compressed Air Supply
              110 - 170 psi (7.6 - 11.7 bar)
              Adjustable Four-Claw Clamp
              Included
              Integrated Bead-Seating Jets
              Included
              Pressure Timer
              Included
              Twin Cylinder Turntable Clamping
              Included
              Rotation Speed
              6.5 rpm
              Bead Breaker Power
              2700 lbs (12 kN)
              Bead Breaker Range
              1.7″ - 16.3″ (43 - 414 mm)
              Recommended Floor Space (WxDxH) 53″ x 46″ x 81″
              Shipping Weight 750 lbs (340 kg)
              Power Requirements 115 V, 1 Ph, 50/60 Hz, 12 Amp

              Compliance and Restrictions

              WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
