Haltec | SKU: 89XDA

Haltec | Aluminum Wall-Mounted Automatic Automotive Tire Inflator (89XDA)

Name: Haltec | Aluminum Wall-Mounted Automatic Automotive Tire Inflator (89XDA)
Brand: Haltec
SKU: 89XDA
Price: 1099.99 USD
Availability: InStock

$1,099.99

Join CLUB5 at Tire Supply Network & Save 5% on EVERY Order! Join Now!

Haltec | Aluminum Wall-Mounted Automatic Automotive Tire Inflator (89XDA)

Ideal for Vehicle Service Centers, Automobile Dealerships and Rental Facilities:

1/4″ inlet/outlet
Operating Range: 5-145 PSI

Features and Benefits of all Haltec Automatic Tire Inflators:

Custom faceplates with corporate logo and color available.
Can be hardwired and mounted to mobile service trucks.
Systems confirm calibration every six minutes when in use and every time they are powered on.
Accurate to +/- 0.3 PSI.
International Protection Rating: IP66, provides complete weather protection (except submersions).
Automatically inflates or deflates to target PSI when attached to tire position.
All systems can be programmed to specific PSI parameters to help organizations better manage consistent and accurate tire inflation.
Wirelessly receives/transmits gauged and corrected pressure via Bluetooth, Zigbee, or hardwired to PC.
Designed to be operated with specific Haltec air chucks.
Nitrogen compatible - PSI is PSI, accuracy is main goal.
All systems allow technician remote control of inflation/deflation process, keeping themselves out of "blast zone" of tire.

TECHNICAL DATA	Automotive Automatic Tire Inflator
Haltec Part Number	89XDA
Construction	Die-cast aluminum enclosure (IP66 rating)
Dimensions (WxHxD)	10.6″ x 11.2″ x 4.2″ (269 x 285 x 106 mm)
Power Requirements	11-18Vdc, 8-16Vac, 110-120V 50/60 Hz, 220-240V 50/60 Hz, 12V Battery/Custom
Units of Measurement	psi, kPa, bar, kg/cm²
Accuracy	Up to ± 0.5% FS / 0.3 psi
Display Increment (precision)	1 psi, 5 kPa, 0.1 bar, 0.1 kg/cm²
Operating Temperature	32°F to 140°F (0°C to +60°C) without heater, -4°F to 140°F (-20°C to +60°C) with heater
Maximum Operating Pressure	145 psi, 1000 kPa, 10.0 bar
Minimum Operating Pressure	5 psi, 35 kPa, 0.3 bar
Maximum Inlet Air Supply	150 psi, 1035 kPa, 10.3 bar
Recommended Inlet Air Supply	10 psi, 70 kPa, or 0.7 bar above the maximum set pressure
Shipping Weight	11.9 lbs (5.4 kg)
