Rotary | Shop 2D Wheel Balancer (R138)
PLEASE NOTE: Additional verification may be necessary for delivery of your equipment order. A customer service representative may call you to assist in finalizing your purchase.
This first level motorized balancer offers a great value to any shop. Its small footprint and lower rotational speed offers features even the most demanding operator will appreciate. A heavy-duty 40mm shaft, large 10.5″ offset for deep rims, easy to read display, and standard accessories offering completes this great package.
- Automatic Program
- Automatic Start
- Caliper
- Digital Display
- Hidden Weight Program
- Made in Italy
Other Features:
- Auto Stop on Top Auto Lock: When the cover is lowered, the R138 automatically begins to spin the shaft. The balancer automatically stops in the external unbalanced position.
- Automatic Program: Automatic measurement of distance and diameter thru ALU programs.
- Bright red, easy to read digital display.
- Perform aluminum wheel balancing with hidden weights above the spokes of the wheel.
Standard Equipment:
- (1) Diameter caliper gauge
- (1) Weight hammer
- (1) 3.5oz Test weight (100g)
- (3) Passenger tire cone kit (1.75″ to 4.4″)
- (1) Light truck cone (3.75″ to 5″)
- (1) Quick nut locking unit
Warranty: 3 years on parts, 1 year on labor
| TECHNICAL DATA | R138 |
| Wheel Diameter | 10″ - 26″ |
| Tire Width | 1.5″ - 22″ |
| Maximum Tire Diameter | 35.4″ |
| Maximum Assembly Weight | 143 lbs (65 kg) |
| Read Out Accuracy | 1 g |
| Cycle Time | 7 seconds |
| Rotation Speed | Less than 100 rpm |
| Power Supply | 110 V / 60 Hz / 1 Ph |
| Height | 46.5″ / 63″ with hood up |
| Width | 39.5″ |
| Depth | 29.125″ |
