Hofmann | Monty 8100S SmartSpeed Center-Post Swing-Arm Tire Changer (EEWH768AC)
PLEASE NOTE: Additional verification may be necessary for delivery of your equipment order. A customer service representative may call you to assist in finalizing your purchase.
The Monty 8100S center post tire changer is designed for easy use with minimal training of technicians reducing shop overhead and adding to your bottom line. Traditional center post design coupled with Hofmann's innovative feature set makes this tire changer highly productive and reduces the risk of wheel damage.
Center Post Clamp Design:
- Reduces risk of wheel damage
- Accommodates a wider range of wheel sizes
Swing-Arm Style Mount/Demount:
- Traditional mounting head with tire lever
- Quick change design, non-marring plastic and metal mount/demount tools included
Bead Pusher/Tire Lifting Tool:
- Integrated bead pusher assists in the mount/demount process of the upper bead
- Tire lifting tool aids the technician with the demounting process
Hand Activated Bead Breaker:
- Side mounted bead breaker
- Thumb switch activation at the point of use
smartSpeed Technology:
- Rotational speed maximized by automatic inverter control
- Variable from 7 RPM to 20 RPM offering the highest possible speed for maximum productivity
Integrated Wheel Lift:
- Assists technicians with lifting and positioning heavy tires/wheels on the machine
- Integrated roller board eases bead breaking
Accessories Included:
- Smart Bead Spacer
- Plastic Protector Bead Breaker Shovel
- Lube Brush & Paste Bucket
- Quick Exchange Toolkit
- Hub Cones
- Plastic Rim Protector
- Plastic Tire Protection
- Mounting Head Protection
- Tire Lever
Technical Data | Monty 8100S with smartSpeed |
Hofmann Part Number | EEWH768AC |
Vehicles Supported | Passenger Car, Light Truck, SUV |
Tower Type |
Manual Swing Arm |
Maximum Tire Diameter |
44″ (1120 mm) |
Maximum Wheel Width |
15″ (380 mm) |
Maximum Rim Width |
14″ (356 mm) |
Reverse Rim Clearance |
15″ (380 mm) |
Mounting Head Range (Rim Diameter) |
12″ - 30″ (305 - 762 mm) |
Wheel Lift Capacity |
154 lbs (70 kg) |
Power Supply Requirements | 230 V, 1 Ph, 50/60 Hz, 17 Amp |
Air Pressure Requirements | 116 - 174 psi (8 - 12 bar) |
Dimensions (WxDxH) | 40″ x 58″ x 75″ |
Net Weight | 881 lbs (400 kg) |
Compliance and Restrictions
⚠️WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
