Forward Lift  |  SKU: I12N301BK

Forward Lift I12PRO | 2-Post Lift 12,000-lb Capacity - 178" Symmetric Columns 3-Stage Arms - Choose Color

Sale price $10,903.26 Regular price $12,114.73

Join CLUB5 at Tire Supply Network & Save 5% on EVERY Order! Join Now!

As low as $151.43 for 72 months Finance Now!


Color

Shipping & Delivery — Lift Gate Required

⚠ Please select a delivery option before adding to cart.


Forward Lift I12PRO 2-Post Lift 12,000-lb Capacity - 178" Symmetric Columns 3-Stage Arms - Choose Color (I12N301)

  ROTARY REBATE PROMOTION - NOW THROUGH JUNE 30th, 2026

Forward’s 12,000-pound capacity I12PRO two-post lift is gold-certified and perfect for raising most passenger cars, trucks, and vans. It has two heavy-duty push hydraulic cylinders designed to increase lift performance and minimize downtime. The durable, powder coat finish provides exceptional protection from the wear a shop will see over the years.

Features
  • Overhead cable equalization
  • Single Point lock release
  • Includes adapter storage bracket
  • ALI Gold Certified

Front & Back Three-Stage Arms
The 112 has our special three-stage arm design in the front and back arms, which provides added versatility regarding the types of vehicles you need and want to service.

Reliable Cylinders
The cylinders on this lift are well-engineered and reliable. There are hydraulic cylinders in each column. They operate using direct pull-lifting technology. They are top-mounted and full-stroke. The cylinder rod is concealed inside the carriage.

Easy to Operate
This lift features a single-point lock release for easy operation.

ALI Gold Certified
This lift has been tested and gold-certified by ALI/ETL, meeting the highest industry safety and performance standards.

*Installation not included.

Specifications
Model
I12PRO
Total Capacity 12,000 lbs. (5443kg)
Max. Rise with 5″ Extension 77 1/2″
Adjustable Overall Height Options 13′ 10″ Standard Height (SKU: I12N300), 14′ 10″ Extended Max. Height (SKU: I12N301), 12′ 10″ (SKU: I12N302), 11′ 11″ (SKU: I12N303)
Overall Width 11′ 8″ or optional 12′ 2″
Drive-Through Clearance 102 3/4″ or optional 108 3/4”
Overhead Switch Height Options 160 1/8″ Standard (SKU: I12N300), 172 1/8″ Extended (SKU: I12N301), 148 1/8″ (SKU: I12N302), 137 1/8″ (SKU: I12N303)
Front Arm Reach (Min./Max.) 27-5/8″ min / 59″ max (700mm / 1500mm)
Rear Arm Reach (Min./Max.) 27-5/8″ min / 59″ max (700mm / 1500mm)
Lifting Pad Height (Min./Max.) 4-3/4″ (121mm) with no extension, 9-3/4″ with 5″ extension (248mm)
Width Between Columns 114 7/8” Standard, 120 7/8″ Optional
Speed of Rise 60 seconds
Voltage/Amps 208-230V, 17 Amps
Motor/Phase 2 HP / 60 Hz / 1 PH
    Warranty:
    5 Years (Columns, arms, runways, and carriages) 18 Months (Cylinder, power unit and parts)
    1 Year Accessories (Parts only) 6 Month Labor
