The 1070 wireless aligners is the total package when it comes to 3D wheel alignment. Simply access programs by selecting 5 command keys that guide the alignment tech through the step by step measuring process. It’s equipped with a powerful PC, an A4 printer and a robust mobile cabinet for attaching and charging the wheel clamps.

This 8-CCD sensor wheel alignment system uses infrared transmission among measuring heads and Bluetooth® communication between the front head and the control unit. Quickly enter vehicle information by model or VIN number and begin the process via a 3D animated workflow

• Bluetooth Transmission
• Quick Charge Supports
• 8-CCD Sensors
• Wheeled Control Unit
• Safe Print Documentation
• 3D Graphic Animation Interface
• Made in Italy

Other Features:

• Customer data bank for recording up to 20,000 jobs with search by customer name or vehicle plate number
• Quickly measure wheel run out by moving the vehicle only 30°
• The Spoiler Program automatically activates to perform measurements on sport and tuned cars through a simple process
• Data bank with more than 90,000 vehicle data sheets
• User’s instructions by animated graphics
• The quick measurement of axle set back, wheelbase and track-width, may highlight any errors in the vehicles body and chassis symmetry
• Dynamic data bank automatically modifies the alignment specifications based on chassis height
• Precise display of the adjustment points
• The steering procedure is carried out electronically through the CCD sensors, so the caster and king pin are measured with precision

Standard Equipment:

• (1) control unit with PC, 19” monitor, keyboard, printer and battery charger
• (2) front and rear measuring heads
• (4) 3-point STDA35E clamps with targets
• Set of 6 extensions for dually wheels
• (1) brake pedal depressor
• (1) steering wheel lock
• Instruction manual on USB drive

Warranty:

3 years on parts, 1 year on labor

Specifications:

• Power supply: 110v / 60 Hz / 1 PH
