BelAire | 60 Gallon Electric Air Compressor - 1PH, 5HP - Vertical (4916V)
PLEASE NOTE: Additional verification may be necessary for delivery of your equipment order. A customer service representative may call you to assist in finalizing your purchase.
The BelAire 4916V delivers reliable 5 horsepower performance on standard 230 volt single-phase power, producing approximately 16 CFM at 100 PSI and around 14 CFM at its maximum pressure of 165 PSI. This makes it a strong choice for moderate-duty air tool use in smaller shops or home garages needing dependable airflow.
Its compact vertical design features a 60-gallon ASME-certified tank, providing ample air storage while conserving valuable floor space. Standing under 70 inches tall, it fits easily in areas with height limitations without sacrificing performance.
Features:
- Two -Stage solid cast iron pump is designed for superior quality & extends the life of the pump
- Compact design is ideal for work environments where space is a premium
- 5 HP single phase motor saves money, no need to purchase an additional starter
- ASME certified tank 100% factory tested at full pressure
- Fully enclosed high flow belt guard provides added safety
- Oil level sight glass allows you to easily check the oil level at any time
- Start/Stop pressure switch control saves time and energy
- Stainless steel valves extends the life of the compressor
Specifications:
Motor
| Voltage |
230 Volt AC |
| Phase |
Single-Phase |
| Magnetic Starter |
No |
| Amp Draw |
22 |
| Recommended Breaker |
40 Amp Breaker |
Engine
Pump
| CFM |
16.1 |
| CFM Rated @ |
100 PSI |
| Pump Material |
Solid Cast Iron |
| Max PSI |
165 PSI |
| Oil Sight Glass |
Yes |
| Pump Type |
Single-Stage |
| After Cooler |
No |
| Pump Drive |
Belt Drive |
| Oil Type |
Oil Lubricated |
| Oil System |
Splash Lubrication |
| Pump Low Oil Shut-Off |
No |
Tank
| Tank Size |
60 Gallons |
| Tank Outlet |
1/2 Inch |
| Electronic Drain Valve |
No |
| Tank Orientation |
Vertical |
Accessories
| Pressure Gauge |
Yes |
| Air Dryer |
No |
Overview
| Weight |
250 Pounds |
| Certification |
ASME |
| Consumer Warranty |
2 Year |
| Product Length |
22.9 Inches |
| Product Width |
27.2 Inches |
| Product Height |
69.7 Inches |
| Power Type |
Electric |
