Chicago Pneumatic | 3/4" Drive Impact Wrench (CP7763)
Join CLUB5 at Tire Supply Network & Save 5% on EVERY Order! Join Now!
Chicago Pneumatic | 3/4" Drive Impact Wrench (CP7763) is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Description
Description
Chicago Pneumatic | 3/4" Drive Impact Wrench (CP7763)
For operators working in maintenance applications or tire changing applications who are looking for a durable, lightweight, yet powerful tool, the CP7763 series is the 3/4" impact wrench for you.
The CP7763 Series impact wrench features a 3/4" square drive and delivers reverse torque up to 1,630 Nm / 1,200 ft-lbs Designed for general maintenance and tire changing, its twin hammer impact mechanism and its composite housing offer high durability in bolting and unbolting applications while also being lightweight and compact.
The CP7763 provides maximum operator comfort and control attributable to great engineering and ergonomics even at high torque levels. With a powerful motor and durable clutch, the CP7763 is ideal for oil, gas & petrochemical, or mining requirements, as well as general maintenance applications.
Features:
- Ideal for general maintenance applications and tire changing
- Powerful motor and durable clutch
- Ergonomic handle for operator comfort
- 3/4" impact wrench with ring retainer
- Twin hammer high performance clutch
- High power: 1,200 ft-lbs (1,627 Nm)
- Combined power regulator with forward/reverse
TECHNICAL DATA | CP7763 |
---|---|
Manufacturer Part Number |
8941077630 |
Actual Air Consumption | 30 cfm |
Air Inlet Thread Size |
3/8″ |
Average Air Consumption | 7.5 cfm |
Blows Per Minute | 900 |
Clutch Type |
Twin Hammer |
European Standards |
EN ISO 11148-6:2013 |
Free Speed | 6300 rpm |
Handle Type |
Pistol |
Length |
8.8″ |
Maximum Torque (Reverse) |
1200 ft.lbs |
Minimum Hose Size | 1/2″ |
Net Weight |
11.57 lbs |
Power/Weight Ratio | 103.7 ft-lb/lb |
Side to Center | 1.8″ |
Socket Retainer | Friction Ring |
Sound Power | 107 db(A) |
Sound Pressure | 96 db(A) |
Square Drive | 3/4″ |
Vibration | 10.4 m/s² |
Vibration ISO | ISO-28927-2 |
Vibration Uncertainty (K) | 4.2 m/s² |
Working Torque Range (FWD) |
100 - 950 ft-lbs |
Compliance and Restrictions
⚠️WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
