BendPak | 2-Post Lift 20,000 lb Capacity / Clearfloor / High-Rise / 192" O.A. Height / Post Extension 20AP-192 (5175615)
Join CLUB5 at Tire Supply Network & Save 5% on EVERY Order! Join Now!
As low as $363.81 for 72 months Finance Now!
BendPak | 2-Post Lift 20,000 lb Capacity / Clearfloor / High-Rise / 192" O.A. Height / Post Extension 20AP-192 (5175615) is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Description
Description
BendPak | 2-Post Lift 20,000 lb Capacity / Clearfloor / High-Rise / 192" O.A. Height / Post Extension 20AP-192 (5175615)
PLEASE NOTE: Additional verification may be necessary for delivery of your equipment order. A customer service representative may call you to assist in finalizing your purchase. Customer must have a Forklift for delivery and Installation is NOT included with purchase.
- Durable powder coat finish
- Expandable top beam accommodates wide or narrow drive-thru configurations
- Double-telescoping screw pads offer increased versatility
- Padded overhead safety shutoff bar
- Single-point safety release
- Drop-end arms provide a lower pad height
- Dual hydraulic direct-drive cylinders
- Electric / hydraulic HVLP power system
- Self-lubricating dura-glide UHMW polyethylene bearing system
- Automatic arm restraints withstand over 2000-pounds of side force
- Oversized cable sheave diameter reduces cable fatigue
- ALI Certified
Specifications:
Lifting Capacity - Front Axle | 20,000 lb (9,072 kg) |
Max. Capacity - Front Axle | 10,000 lb (4,536 kg) |
Max. Capacity - Rear Axle | 10,000 lb (4,536 kg) |
Max. Rise | 76.25" (1,934 mm) |
Lifting Height w/ Pad 1 | 83" (2,111 mm) |
Max. Lifting Height 1 | 91.5" (2,327 mm) |
Min. Height w/ pad | 8" (206 mm) |
Height Overall | 193" (4,904 mm) |
Width Overall | 168" (4,267 mm) |
Outside Posts | 149" (3,785 mm) |
Inside Posts | 126" (3,199 mm) |
Drive-Thru Width | 107.75" (2,739 mm) |
Floor to Top Switch | 186.5" (4,738 mm) |
Front Arm Reach | 35 - 62" (893 - 1,678 mm) |
Read Arm Reach | 35 - 62" (893 - 1,678 mm) |
Base Plate Width | 28" (710 mm) |
Post to Base Plate | 9.5" (241 mm) |
Max. load per Lift Arm | 5,000 lb (2,268 kg) |
Motor2 | 220 VAC, 60 Hz, 1 Phase |
Sound | <70 dB |
INFORMATIONAL LINKS:
Study in Lift Designs | Electrical & Utility | Concrete Specs |
Balancing Safety | How to Level | Best Car Lift Guide |
Things to Know | Specifications | Warranty |
20AP-192
From heavy-duty fleet service to airport maintenance and emergency vehicle management, BendPak’s 20AP Series tackles them all. With an astounding 20,000-pound lifting capacity combined with long-reaching telescoping arms and a sizeable assortment of lifting adapters to accommodate virtually every chassis configuration, our Super-Duty AP Series makes an ideal supplement to existing fleet operations. Over 50 years of lift-building heritage perfectly delivered.
With oversize dimensions and capabilities that go well beyond those typically found on traditional two-post lifts, they lift more, lift higher, reach farther, and realize more vehicle-supporting stability than ever before. And with fewer moving parts, they’re less susceptible to wear and tear, easier to maintain and less expensive to operate. And that all adds up to a cost-savings advantage you’ll appreciate regardless of your environment. More uptime means more free time. From accommodating large commercial trucks safer than ever before and lifting and supporting long awkward vehicles effortlessly, our Super-Duty AP Series handles heavy fleet tasks very comfortably. The key? Graciously spaced columns make for easier entry and exit and ruggedly built far reaching arms increase lifting point coverage delivering greater stability. Ergonomic operator controls allow for simple and safe operation, a benefit that boosts productivity resulting in higher output and greater profitability.
Every day the automotive industry evolves with new and advanced technologies, meaning that it’s crucial for auto repair shops to keep pace by outfitting themselves with the best of the best. That’s where the 20AP-192 comes in. As part of the revolutionary AP Series, this lift marks a new era in car lift engineering. It has been meticulously crafted to integrate the best features from existing two-post lift types into an entirely new concept, catering to extreme use, heavy loads, and operator safety and efficiency. The 20AP-192 delivers everything professionals love about the AP Series in a taller package. With an increased 193” overall height, techs will have more room to work comfortably.
Need replacement parts? Call or email us and we can special order them for you!
