Why Proper Setup Matters
ADAS calibration accuracy depends heavily on environmental conditions. Improper setup leads to failed calibrations and liability risks.
Minimum Space Requirements
Typical static calibration requires:
- 20–30 ft front clearance
- Level floor surface
- Centered vehicle positioning
(Some automated systems reduce measurement complexity.)
Floor Requirements
- Flat within manufacturer tolerance
- No slopes or uneven concrete
- Alignment rack compatibility preferred
Lighting Conditions
Incorrect lighting affects camera calibration.
Recommended:
- Even overhead lighting
- No direct sunlight interference
- Minimal shadows behind targets
Common Setup Mistakes
- Calibrating on uneven surfaces
- Incorrect distance measurement
- Obstructed targets
- Poor wheel alignment prior to calibration
Planning for Growth
Designing calibration space correctly allows shops to expand services without relocating equipment later.
